Application field and installation bracket

Specifications and features

• Type of protection	Gas : Ex d IIC T6 Gb (KCs/IECEx/ATEX) Dust : Ex tb IIIC T85°C Db (KCs/IECEx/ATEX) Location : Zone 1, 2, 21, 22
  Degree of protection	IP67
  Ambient Temperature	-40°C ~ +70°C
  Material	Electro-polished SUS 316L
  Cable Entry	¾” NPT -14
  Pan Range	360° Endless
  Tilt Range	± 90°
  Pan/Tilt Travel Speed	0.05 ~ 60 °/sec
  	IR LED (740nm, Max200m)
  	Preset / Tour / Home Function
  	FAN, Heater (Option)
  Input power	AC100~240V, 50/60Hz or DC24V
  Weight	30kg
